SPS Case 150W 12V/12,5A

Gruppe: L6251MEANWELL Switching Power SuppliesSeries: S-150Case, Single OutputOutput: 150 to 156WFeatures• Enclosed case, screw terminals• AC input range 115V/230V selectable by switch• Overload protection, pulsing hiccup shutdown, auto recovery• Protections: short circuit/over load/over voltageTechnical SpecificationsInput Voltage:88...132/176...264V AC (47...63Hz)248...370V DCInput Inrush Current, Max.:35ALeakage Current, Max.:3,5mAOutput Voltage Adjustment:±10%Over Load Protection:105...150%Withstand VoltageI/P-O/P:3000V ACI/P-FG:1500V ACO/P-FG:500V ACOperating Temperature:-10...+60°CWeight:800gI/P = Input, O/P = Output, FG = Frame GroundPart Nr.UAIAPADUAURNh [V][A][W][%][mVp-p][%]S-150-550...30150215078S-150-7.57,50...20150115080S-150-990...16,7150,3118080S-150-25120...12,5150118082S-150-15150...10150118084S-150-24240...6,5156124085S-150-27270...5,6151,2124086S-150-48480...3,2153,6124087UA = Output Voltage, IA = Output Current Range, PA = Output Power, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = EfficiencyNoteThis series corresponds to EN61000-3-2 Class A and may only be used in ranges with this standard.You will find installation material in product group L6911.Labelling Terms of DeliveryMinimum order quantity: 1 PKU = 1 pieceManufacturer http://www.meanwell.com
