UNI-T UT120B Digital Multimeter, 600VAC

UNI-TREND UT120B Multimeter i lommestørrelseRobust ABS husLCD-display: 1.7"LCD-størrelse: 43 mm x 22 mmAutomatisk slukKabellængde 80 cmAC Målingsspændin max 600VAC Målingsspænding min. 4VDC Målingsspænding max 600 VDC Målingsspænding min. 400 mVFrekvens min. 10 HzFrekvens maks. 10 MHzModstandsmåleområde, maks. 40 MOhmModstandsmåleområde, 0-40MohmAndre måleområder Kapacitans: 4 nF ... 100 uFDisplaytype LCDBatteritype 1x CR2032, 3V (knapcelle)Gennemgangstest: JaKalibreret: NejSikkerhedskategori CAT II 600 VVægt: 76 g1. Auto range2. Auto polarity prompt3. Relative mode4. Data hold5. Auto power off6. Capacitance measurement7. Comply with CE (European Union) directivesSpecificationsRangeBest AccuracyModel　UT120B DC Voltage (V)400mV/4V/40V/600V±(0.8%+1)AC Voltage (V)4V/40V/400V/600V±(1.2%+3)DC Current (A)400μA/4mA/40mA/400mA　AC Current (A)400μA/4mA/40mA/400mA　Resistance (Ω)400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ±(1%+2)Capacitance (F)4nF/40nF/400nF/4μF/40μF/100μF±(4%+3)Frequency (Hz)10Hz~10MHz±(0.5%+3)FeaturesDisplay Count　4000Auto Range　√ Duty Cycle0.1%~99.9%√ Diode　√ Auto Power OffAround 30 Minutes√ Continuity Buzzer　√ Low Battery Indication≤2.4V√ Data Hold　√ Relative Mode　√ Input Impedance for DCVAround 10MΩ√ General Characteristics Power3V Battery (CR2032)LCD Size43mm X 22mm     Product ColorRed and greyProduct Net Weight76gProduct Size110mm X 58.2mm X 10.8mmStandard AccessoriesBattery, Carrying CaseStandard Individual PackingBlister, English ManualStandard Quantity Per Carton100pcsStandard Carton Measurement750mm × 275mm × 490mm (0.1CBM Per Export Carton)Standard Carton Gross Weight21.9kg
