SPS Open Frame 40W 5/12V

Gruppe: L7151MEANWELL Switching Power SuppliesSeries: PD-45Open Frame, Dual OutputOutput: 40 to 45WFeatures• Open frame• Contact pin for nylon-crimp terminals• Universal input• Overload protection, pulsing hiccup shutdown, auto recovery• Protections: short circuit/over load/over voltageTechnical SpecificationsInput Voltage:90...264V AC (47...440Hz)127...370V DCInput Inrush Current, Max.:30ALeakage Current, Max.:0,75mAOutput Voltage Adjustment, Channel 1:4,75...5,5VOver Load Protection:53...75WWithstand VoltageI/P-O/P:3000V ACI/P-FG:1500V ACO/P-FG:500V ACOperating Temperature:-10...+60°CWeight:200gI/P = Input, O/P = Output, FG = Frame GroundPart Nr.UAIAPA1)DUAURNh [V][A][W][%][mVp-p][%]PD-45A50,4...54045077 120,2...2,5 7120 PD-45B50,4...544,845078 240,2...1,8 7150 UA = Output Voltage, IA = Output Current Range, PA = Output Power, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency, 1) The Sum of the Power Used by the Individual Channels Must Not Exceed the Total Power Rating.NoteYou will find suitable crimp housings in product group L7611.Labelling Terms of DeliveryMinimum order quantity: 1 PKU = 1 pieceManufacturer http://www.meanwell.com
