SPS DIN-Rail 96W 24V/4A

Gruppe: L5137MEANWELL Switching Power SuppliesSeries: MDR-100DIN-Rail Assembly, Single OutputOutput: 90 to 96WFeatures• Direct assembly on DIN Rail• Enclosed case, Touch-guard screw terminals• Universal input• Overload protection, current limiting, auto recovery• Protections: short circuit/over load/over voltage• Power-on LED display• Low no load power consumption• DC OK relay contact• NEC Class 2 compliantTechnical SpecificationsInput Voltage:85...264V AC (47...63Hz)120...370V DCInput Inrush Current, Max.:60ALeakage Current, Max.:1mAOutput Voltage Adjustment:+20%No Load Power Consumption, Max.:1WOver Load Protection:105...150%Withstand VoltageI/P-O/P:3000V ACI/P-FG:1500V ACO/P-FG:500V ACOperating Temperature:-10...+70°CWeight:420gI/P = Input, O/P = Output, FG = Frame GroundPart Nr.UAIAPADUAURNh [V][A][W][%][mVp-p][%]MDR-100-12120...7,590112085MDR-100-24240...496115086MDR-100-48480...296120088UA = Output Voltage, IA = Output Current Range, PA = Output Power, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = EfficiencyLabelling Terms of DeliveryMinimum order quantity: 1 PKU = 1 pieceManufacturer http://www.meanwell.com
