SNT extern 60W 18V/3,33A

Features• Desk Top Type• Universal Input• Power-On LED• Ultra Compact Design• Overload and Continuous Short Circuit Protection• High EfficiencyApplication• Printer• External HDD• Computer Applications• Control Equipment• Microprocessor Systems• Laptop, NotebookTechnical Specifications  PowerPSA60W112,PSA60W115:50WPSA60W118, PSA60W119, PSA60W124:60WOperating Temperature Range:0...+35°CStorage Temperature Range:-25...+75°CHumidity:5...95% RHLeakage Current:<0,25mA/240V ACDielectric Withstand (Hipot):Input- Output 3KV ACMTBF:MIL-HNBK 70000hInput  Input Voltage Range:90...264V ACInput Frequency:47...63HzAC-Surge:IEC 61000-4-5, Level 3Hold-Up Time, Nom. Conditions:20ms min.In-Rush Current Cold, Max.120V AC:<55A240V AC:<100AOutput  Power, Max.:60WEfficiency, Typ.:80%Switching Frequency:70KHzOvervoltage Protection:>120%Overcurrent/Short-Circuit Protection:>120%, Auto RestartDielectric Withstand (Hipot), Input-Output:3000V AC, 1Min.All technical specifications are applicable toTU = 25°CSelection Table     Part Nr.OutputLoad IARWRegulation [V][A][mV][%]PSA60W112120...4,16120±4PSA60W115150...3,33150±4PSA60W118180...3,33180±4PSA60W119190...3,16190±4PSA60W124240...2,50240±4IA = Output Current, RW = Ripple & NoiseNoteYou will find suitable cable appliances in our blue "Passive Components" catalogue at product group G1513.Marking
