SPS Case 240W 48V/5A

GROUP:L6345Gruppe: L6345MEANWELL Switching Power SuppliesSeries: SP-240Case, Single OutputOutput: 225 to 240WFeatures• Enclosed case, built-in fan, screw terminals• Universal input• Overload protection, current limiting, auto recovery• Protections: short circuit/over load/over voltage• Built-in active PFC functionTechnical SpecificationsInput Voltage:88...264V AC (47...63Hz)124...370V DCInput Inrush Current, Typ.:40ALeakage Current, Max.:2mAOutput Voltage Adjustment:±10%Over Load Protection:105...135%Withstand VoltageI/P-O/P:3000V ACI/P-FG:1500V ACO/P-FG:500V ACOperating Temperature:-20...+70°CWeight:800gI/P = Input, O/P = Output, FG = Frame GroundPart Nr.UAIAPADUAURNh [V][A][W][%][mVp-p][%]SP-240-550...45225215079SP-240-12120...20240115086SP-240-15150...16240115086SP-240-24240...10240115088SP-240-30300...8240115088SP-240-48480...5240115089UA = Output Voltage, IA = Output Current Range, PA = Output Power, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = EfficiencyNoteYou will find installation material in product group L7617.Labelling Terms of DeliveryMinimum order quantity: 1 PKU = 1 pieceManufacturer http://www.meanwell.com
