Transformer 10VA 2x115V 2x12V 2x416mA

Gruppe: D7713HAHN Flat TransformersCore: UI30Non Short-Circuit ProofOutput: 6...16VAInput Voltage: 2x115VConstruction• Vacuum encapsulated, bobbin with two chambers• Leads through soldering pins to accommodate PCB mounting • Designed to match VDE 0570 and EN61558 regulations• Fully tested at primary and secondary voltage of 6000V, leakage and sparking distance in air is at least 10mm• Types with double primary and secondary windings (2x115V) suitable for application in 115V as well as 230V power suppliesElectrical SpecificationsPart Nr.P1)SecondarySecondaryNo-Load  VoltageCurrent2)Voltage [VA][V][mA][V]BVUI303015862x92x33412,8BVUI303014562x122x25017,2BVUI303016362x152x20021,8BVUI303014362x182x16626,0BVUI303017062x212x14329,7BVUI3040155102x62x8338,7BVUI3040129102x7,52x66710,0BVUI3040153102x92x55512,4BVUI3040154102x122x41616,0BVUI3040136102x152x33319,7BVUI3040159102x182x27723,3BVUI3040173102x212x23827,2BVUI3050147162x62x13307,5BVUI3050148162x92x88810,9BVUI3050149162x122x66614,63BVUI3050150162x152x53318,0BVUI3050151162x182x44421,5BVUI3050152162x212x38025,0P = Power, 1) Primary Voltage at 230V, 2) Secondary Voltage per Winding ±5%SizePerformanceHeight hWeight  [mm][g] 6VA22,8180 10VA28,8260 16VA37,6370 Approvals 05Terms of DeliveryMinimum order quantity: 1 PKU = 1 pieceArticles in bold print in stock, other articles of 100 pieces upwards available on request, delivery time approx. 5 weeks.ManufacturerHAHN GmbH & Co. KG http://www.hahn-trafo.com

• Kategori: 222
