Transformer 18VA 2x115V 2x6V 2x1500mA

Construction• Vacuum encapsulated, bobbin with two chambers• Leads through soldering pins to accommodate PCB mounting • Designed to match VDE 0570 regulations• Fully tested at primary and secondary voltage of 6000V, leakage and sparking distance in air is at least 10mm• Types with double primary and secondary windings (2x115V) suitable for application in 115V as well as 230V power suppliesElectrical SpecificationsPart Nr.P1)SecondarySecondaryNo-LoadVoltageCurrent2)Voltage[VA][V][mA][V]BVUI3930085142x62x11668,3BVUI3930074142x92x77812,4BVUI3930081142x122x58316,5BVUI3930062142x182x38924,7BVUI3930096142x212x33428,8BVUI3940086182x62x15008,7BVUI3940073182x7,52x120010,2BVUI3940063182x92x100013,0BVUI3940087182x122x75016,7BVUI3940088182x152x60020,4BVUI3940075182x182x50023,6BVUI3940097182x212x42824,7BVUI3950098242x92x133311,4BVUI3950091242x122x100014,9BVUI3950083242x152x80018,5BVUI3960102302x92x166611,3BVUI3960079302x122x125015,0BVUI3960103302x152x100018,6P = Power, 1) Primary Voltage at 230V, 2) Secondary Voltage per Winding 5%SizePerformanceHeight hWeight[mm][g]14VA25,233018VA28,539024VA32,046030VA36,0550Approvals 05Terms of DeliveryMinimum order quantity: 1 PKU = 1 pieceArticles in bold print in stock, other articles of 100 pieces upwards available on request, delivery time approx. 5 weeks.ManufacturerHAHN GmbH & Co. KG http://www.hahn-trafo.com
